Engine

.750" x .1880" thick Woodruff Key for the crankshaft 1955-1968 V8 Models 1966-1980 All Models 1981-1995 All Models up to VIN 55760

This is the washer for the front core plug on the left hand & right hand side of the engine block.The rear plug washer on the left side is XB1095R & on the right side is XB1078R.  1959-1965  Silver Cloud II,III, S-2,3, Phantom...

This is the spark plug washer, 1 per plug. All Rolls-Royce and Bentley Models from 1959-1989 year models

This is the washer for the crankcase / cylinder head. 1960-1965 Silver Cloud II,III and Bentley S2,3 Phantom V models 1966-1980  Silver Shadow, T-series, Shadow II, T-2, Silver Wraith II 1981-1998 Silver Spirit, Sliver Spur, Mulsanne, Turbo R,...

This washer has a number of applications along with numerous supersessions:1. On the 1959 - 80 Silver Shadow range of cars it is the washer for the reed switch.2. It is also the washer in the fuel line of the Series 2 models.3. It is the sealing washer...

This is the gearbox sump drain plug washer. 1985-2000 All Models (from VIN 12695 onward)

This is a modern rubber valve stem seal that can be fitted to all cars from 1960 onwards as a modification to the original cotton valve stem seal (UE7428). Note: 8 Per Cylinder Head;  16 Required Total Per Car (Sold Each) 1960-1965  All...

These are the original cotton valve stem seals. There are 8 seals per cylinder head.  (16 required per car) 1960-1965 Silver Cloud & S-series & Continental & Phantom V V8 Models 1966-1980  Silver Shadow, T-series, Shadow II, T-2,...

This is a rubber valve stem seal that slides on to the exhaust valve.  1982-1994 Continental, Corniche, Mulsanne, Spirit, Spur, Turbo (VIN 6751-46740)

This is the main spring for the inlet and exhaust valves on all cars from 1960 to 1969 and on the inlet valve only from 1969 to 1986 except Turbo models. 1960-1969 Silver Cloud II, III & Bentley S2,3 & Phantom V 1966-1980  Silver...

This is the Grommet that covers the Rocker Stud.  RPI recommends replacing these grommets when replacing the rocker cover gasket. Note: These  grommets are only suitable for cars fitted with cork rocker cover gaskets. 1959-2000 All V8 Models...

Rubber Valve Cover Gasket / Rocker Cover Gasket From 1998 year onward V8 models  Can be retro-fitted to earlier V8 models as long as: 3 new valve cover grommets / isolators (07V109151PB) per head and 3 new distance pieces (UV11307PB) per...

All cars from 1959 through 1997 were originally fitted with these cork rocker cover gaskets.  From 1998 all V8 engine models were fitted with rubber gaskets (UV11305PAP) which can be retro-fitted to all earlier models as long as new isolators...

This is the original style triangle paper gasket. It is fitted to the end of the cylinder head.  Note: 2 Per Car (Sold Each)  RPI offers the plastic style see part number UE75131 / 07V103771. The part number has been superseded several times...

This is the timing cover gasket.   1959-1965 Cloud II,III & Bentley S2,3 & Phantom V 1966-1980 Silver Shadow, T, Shadow II, T-2, Silver Wraith II 1981-1987 Silver Spirit, Silver Spur, Mulsanne & Turbo R (Up to VIN...

This is the tappet for A bank and rear B bank front. Supersession: UE31423 1959-1965 All Models 1966-1980 All Models 1980-1998 All Models 1998-2003 All Models

This is the NGK spark plug. All SZ models after 1994 from VIN 46741 approx All Arnage models from 2002 VIN 08200 onward 2009-2010 Brooklands 2012-2015 Mulsanne

This is the Riser for the Solex Carburetor. 1980-1982 Camargue (VIN 50349-50776) 1982-1987 Continental (VIN 09030-16890) 1982-1987 Corniche (VIN 50307-50757)

This is the rubber plug that sits in the inside of the front timing cover.  1962-1965 V8 Models  1966-1980 Silver Shadow, T-series, Shadow II, T-2, Silver Wraith II  1981-1990 Up to VIN 16970

This is the distance piece for the rocker cover studs. They are required when fitting the later rubber rocker cover gaskets (07V109235A) and bonded isolators (07V109151) to pre-1997 model cars previously fitted with cork rocker cover gaskets. ...

These are the bonded isolators required when fitting the later style rubber rocker cover gaskets (UV11305PA) and spacers (UV11307PB). There are 3 isolators required per cylinder head. Fitted to models from 1997 onward and early V8 models

This is the Rear engine mount.  There are two required per car and are sold each.   Note: 2 required per car (Sold each) 1988-1998 (From VIN 24497 onwards)

This is the Rear Engine Mount.  Also known as the rear motor mount.  There are two per car and located between the engine and gearbox.  (Sold separately)  1966-1980 Silver Shadow, Shadow II, T-2, T-2, Silver Wraith...

This is the horseshoe gasket between the rear crankshaft cover and the crankcase. 1959-1965 Cloud II,III, S-2,3, Phantom V 1966-1980 All Models 1981-1992 Spirit, Spur, Mulsanne, Turbo (up to VIN 36320)

Rear Cam Cover Gasket Supersession: UE5237 1959-1965 Cloud II,III & S2,3 1959-1968 Phantom V 1966-1980 Silver Shadow, T-series, Silver Wraith, T-2, Shadow II 1980-1988 Mulsanne, Spirit, Spur up to VIN 24501

This is the rubber joints for the ram pipes. Note: 8 per Car (Sold Each)  Turbo, Mulsanne, Spirit, Spur, Dawn, Corniche, Continentals from VIN 54001 onwards

This is the gear and spindle for the oil pump assembly.  Note: Original part # UE5826 this number has been superseded by 07V115123 1960-1998 Onward ALL V8 ENGINES

This is an original oil pump driving gear.  Picture shows what looks to be rust. This is NOT rust!  This is cosmoline spray that was put on the part before leaving the Rolls factory. Note: Original part # is UE9691, this has been superseded to...

This is the driven oil pump gear on the crankshaft.  This parts needs to be fitted in conjunction with drive gear UE42783. 1979-1981 (B-series Engines) Silver Shadow II, Wraith II, T2 (VIN 39628-41686) 1980-1984 Silver Spirit, Sliver Spur,...

This is the switch for the light sender. 1980-1989 All models up to 28000
